The motor kit fits 1 1/2" to 1 5/8"(38mm to 40mm) tubes. The motor is specifically designed for preventing sunlight from coming through the installation gap. The motor can be mounted at the left or right side. It can be operated by remotes, timers, wall switches, smartphones, or voice-controlled by Google assistant or Amazon Alexa with a
SmartCtrl-MA Wi-Fi module. It is a great choice for shades, blinds, and many up/down automatic applications.
Note: Integrated into any automation control systems or controllers with relay (dry type) inputs
Features
- Slim design prevents sun light from coming through the installation gap (1/2" on each side)
- Can be mounted on ceiling, wall, or any other angled surface
- Motor runs quietly and remains silent on standby
- Can be easily integrated into any automation control systems or controllers with relay (dry type) inputs
- Can be operated by a timers, wall switches, smartphones, or voice-controlled by Google assistant or Amazon Alexa with a SmartCtrl-MA Wi-Fi module
- Group control to run multiple motors up or down simultaneously or individually
- Stops at any position by pressing "STOP" button
- Double hall feedback sensor for precise position
- Programmed upper/lower positions and 1 middle favorite positions will remain when power is off
Specifications
- Operation voltage: 110 to 240 AC
- Operation power: 19W
- Protection Class: IP44
- Rated RPM: 20/30
- Rated Torque: 14in.lb (1.6N.M)
- Frequency: 868MHz
- Noise: 25-40db
- Working tube size: 1 1/2" (38mm)
- Maximum load with 1 1/2" tube < 17.6lbs (8Kgs)
- Minimum width: 18"
- Maximum width: 142"
- Approximate inside mount fabric deduction: 1"
- Minimum inside mounting depth: 3/4”
- Fully recessed depth: 2” – 3”
Package Content
- One tubular motor CL625E-0226-D
- One RF remote
- Mount brackets
- Drive adapter and idler 1 5/8"(38mm)
- Instruction booklet
Frequently Bought Together
Note: We offer completed sets of made-to-order motorized roller shades. We cut your chosen fabric to your given size and attach it to rods and bottom weight bars. They are ready to go kits. You just install them with simple tools. We have a range of light and privacy controlled options of fabric as well as colors and textures. Click the link to see the choices of fabric. One motor kit can operate two or more rods when using joiners. Contact us for custom motorized roller shade kits.
