Remote Motorized Belt Drive Electric Smart Curtain Rail Track

The motorized Drapery track system is designed for straight line windows, bay windows, corner windows, and any custom curved window (contact us). The track can be set up to open/close from left to right, right to left, or center to both sides. It can be mounted anywhere on the ceiling, or on the wall with adjustable off wall distances between 0.25" to 3.25". The motor can be plugged into your wall outlet or hard-wired into your electrical system. The motor can be mounted on the left or right side. It can be operated by the remote, timer, wall switch, any dry-contact relay controller, optional smartphone and voice-controlled by Google assistant or Amazon Alexa.

Note: If you try to set up a track to cover bay windows and corner windows, you have to order curved tracks separately. The 1350-degree curved track works for most bay windows and requires the straight track kit and two 135-degree curved tracks. The 90-degree curved track works for corner window and requires the straight track kit and one 90-degree curved track.

See how to put it together:  Click here to view the video!

Features

• Can be used for bay windows or corner windows with optional curved tracks(sold separately)
• Automatically program fully open/close two end positions; no limited switch setup
• Can set any position as your favorite position (a position between fully open/close position)
• The motor will intelligently continue to finish opening/closing draperies when starting to open/close draperies by hand
• Can be operated by a remote, timer, wall switch, smartphone, and any other dry-contact-relay controller
• Can be voice controlled by smartphone or Google Assistant or Amazon Alexa with smart control option
• Can be operated by hand when power is off
• Slow start/stop, runs smoothly, precisely, and ultra-quietly
• Overload and jam protection

Specifications

• Operation voltage: 110VAC to 240VAC
• Output power: <48W
• Rated torque: 2n.m
• Rated RPM: 100~120
• Rated currency: 2.3A @ 24VDC
• Frequency: 433.92MHz/863MHZ
• Motor dimesions: 2" X 2-9/16" X 12-3/16"(50mm X 65mm X 310mm)

Curtain loading chart (unit is Kgs):

Package Content

• One selected belt drive motor
• Selected size tracks with carriers and drive belt
• One 1-channel RF remote
• Mounting brackets

• Built-in battery motor is available. Contact us if you want to upgrade.
• The track can be cut down to fit the measurements of your project; just order the next longer size track than you need. Mount hardware and remote control are included in the package; this is a ready-to-go kit! Curtains or draperies are not included.
• For bay windows and corner windows, order one straight track. The straight track length should be the next longer size than the total length of your coverage, and then order required curved tracks. For example, if you have bay window measured as left 50, center 90, and right 50, you need order one 198 (198>50+90+50=190) straight track and another order of two 135-degree curved tracks. Try to make note of bay windows 50-90-50 when you place the order.
